Product Details

System

• Main Processor: Industrial-grade processor
• Operating System: Embedded Linux
• Operating Interface: Web, Local GUI

AI Features

• AI by Recorder: SMD Plus
• AI by Camera: Face detection, face recognition, perimeter protection, SMD Plus, people counting, stereo analysis, heat map

Perimeter Protection

• Perimeter Performance (AI by Camera): 6 channels

Face Detection

• Face Attributes: Gender, age group, glasses, expressions, face mask, beard
• Face Detection Performance (AI by Camera): 6 channels

Face Recognition

• Face Recognition Performance (AI by Camera): 6 channels

SMD Plus

• SMD Plus by Recorder: 4 channels (secondary filtering for human and motor vehicle detection, reducing false alarms)
• SMD Plus by Camera: 6 channels

Audio and Video

• Access Channels: 16 channels
• Network Bandwidth:
• AI Disabled: 160 Mbps incoming, 160 Mbps recording, 80 Mbps outgoing
• AI Enabled: 80 Mbps incoming, 80 Mbps recording, 60 Mbps outgoing
• Resolution Support: 12 MP, 8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 1080p, 960p, 720p, D1, CIF, QCIF
• Decoding Capability:
• AI Disabled: 1-channel 12MP@30fps, 2-channel 8MP@30fps, 3-channel 5MP@30fps, 4-channel 4MP@30fps, 8-channel 1080p@30fps
• AI Enabled: 1-channel 12MP@30fps, 1-channel 8MP@30fps, 2-channel 5MP@30fps, 3-channel 4MP@30fps, 7-channel 1080p@30fps
• Video Output:
• HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720
• VGA: 1920×1080, 1280×1024, 1280×720
• Multi-Screen Display:
• Main Screen: 1/4/8/9/16
• Sub Screen: 1/4/8/9/16
• Third-Party Camera Access: ONVIF, Panasonic, Sony, Axis, Arecont, Pelco, Canon, Hanwha

Compression Standards

• Video Compression: Smart H.265+, H.265, Smart H.264+, H.264
• Audio Compression: G.711a, G.711u, PCM, G726

Network

• Network Protocols: HTTP, HTTPS, TCP/IP, IPv4, IPv6, UDP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, FTP, DDNS, SNMP, Alarm Server, P2P, Auto Registration, IP Search
• Mobile Phone Access: iOS, Android
• Interoperability: ONVIF 22.12 (Profile T, Profile S, Profile G), CGI, SDK
• Supported Browsers: Chrome, IE, Safari, Edge, Firefox

Recording & Playback

• Multi-Channel Playback: Up to 16 channels
• Record Modes: General, motion detection, intelligent, alarm
• Backup Methods: USB device, network
• Playback Modes: Instant playback, general playback, event playback, tag playback, smart playback

Storage

• Disk Group Support: Yes

Alarms

General Alarm:

• Motion detection, privacy masking, video loss, scene changing, PIR alarm, IPC external alarm

Anomaly Alarm:

• Camera disconnection, storage error, disk full, IP conflict, MAC conflict, login locked, cybersecurity exception

Intelligent Alarm:

• Face detection, face recognition, perimeter protection, SMD Plus, people counting, stereo analysis, heat map

Alarm Linkage:

• Record, snapshot, IPC external alarm output, audio, buzzer, log, preset, email

Ports

• Audio Input: 1-channel RCA
• Audio Output: 1-channel RCA
• Alarm Input: 4 channels
• Alarm Output: 2 channels (1-channel 12V 1A output)
• Disk Interface: 2 SATA ports (up to 20 TB per disk, varies with temperature)
• RS-232: 1 port
• USB: 2 ports (1 front USB 2.0, 1 rear USB 2.0)
• HDMI: 1 port
• VGA: 1 port
• Network Port: 1 (10/100/1000 Mbps Ethernet, RJ-45)
• PoE Ports: 16 ports, 10/100 Mbps, IEEE 802.3 af/at

General Specifications

• Power Supply: 100–240 VAC, 50/60 Hz
• Power Consumption:
• NVR Output: <10W (without HDD)
• PoE Output: 130W (Max 25.5W per port)
• Weight:
• Net Weight: 2.60 kg (5.73 lb)
• Gross Weight: 3.80 kg (8.38 lb)
• Product Dimensions (W × D × H): 375.0 mm × 327.9 mm × 53.0 mm (14.76" × 12.91" × 2.09")
• Packaging Dimensions (W × D × H): 451.0 mm × 147.0 mm × 425.0 mm (17.76" × 5.79" × 16.73")
• Operating Temperature: –10 °C to +55 °C (14 °F to +131 °F)
• Storage Temperature: –20 °C to +60 °C (–4 °F to +140 °F)
• Operating Humidity: 10%–93% RH, non-condensing
• Installation: Rack or desktop
